Beskrivelse
The CR-Scan Raptor integrates an innovative combination of blue laser and infrared light sources, covering scanning of small, medium, and large objects, which can meet the needs of diverse industrial 3D scanning scenarios.
Highlights
- 7 Blue Parallel Laser Lines
- Metrology Grade Accuracy, up to 0.02mm
- Scanning Speed up to 60fps
- Objects between 5-2000mm
- Anti-shaking for Smooth Scanning
- Scan Black/Metal Objects Without Sprays
- 24-Bit Full-Color Scanning
- Light and Compact, 372g
BLUE LASER & NIR
The CR-Scan Raptor integrates an innovative combination of blue laser and infrared light sources, covering scanning of small, medium, and large objects, which can meet the needs of diverse industrial 3D scanning scenarios.
7 Blue Parallel Laser Lines
Metrology-grade accuracy, the accuracy under laser scanning mode can achieve up to 0.02mm. 7 parallel blue laser lines for fine scanning details, single laser line is as fine as 0.1mm to obtain sharper and clear point cloud edges.
Infrared Structured Light Scanning
Markerless Scanning: The CR-Scan Raptor utilizes speckle matching 3D imaging, No markers needed for feature-rich workpieces. Objects can be scan quickly and directly.
High-speed Scanning Beyond Your Imagination
Blue Light Scanning Speed: Up to 60fps
NIR Scanning Speed: Up to 20fps
Unique Face & Body Algorithm
Face & body mode is equipped with a unique face mapping algorithm that captures more details, a human body scan only needs as quick as 2 minutes.
Accurate and Detailed Scanning
Advanced temperature compensation algorithm, it can improve temperature stability and ensure accuracy.
Anti-shaking for smooth scanning
Equipped with One-Shot 3D imaging technology, the CR-Scan Raptor is naturally stabilized and less likely to tracking loss. Fast backtracking speed ensures smoother handheld scanning.
Scan Black/Metal Objects without Sprays
Even without scanning spray, you can scan cars, car parts, tires, and other black/metal objects to get the desired model effect.
Versatile Scanning for All Sizes
Combining line lasers with infrared structured light, the CR-Scan Raptor can scan objects ranging in size from 5*5*5 mm³-2000*2000*2000 mm³. Effortlessly scanning small figurines, bolts, faces, human bodies, automobile components, and more.
24-bit Full-Color Scanning
Equipped with 12 circular LED texture lights, it can enhance the brightness of color mapping in dark environments and truly present the color of objects.
Intuitive Experience
Ring indicator light, providing real-time scanning status feedback; Paired with buttons, it offers comfortable and straightforward operation.
Lightweight and Portable, One-hand Control
Lightweight 372g, effectively reduces long-term work fatigue.
High precision glass calibration board
Utilizes high-precision glass substrate calibration board for accuracy calibration, you can maintain the high precision of the scanner, maintain accuracy.
