8.9″ 4K Monochrome LCD
Monochrome screens can last several thousand hours. Monochrome screens allow for very short layer exposure times for faster print times.
Fast Printing Speed
The time of exposure is as low as 1.5-2 seconds, and the max print speed is 60mm/h, making printing speed 3X faster than the Photon.
Large Build Volume
A large build area for your 3D-printed creations :192mm(L)*120mm(W)*245mm(H)
Safe Design
Printer will be immediately shut off if the top cover has been removed. This feature is turned off by default
Anycubic Slicer Software
New features are added to the software. Supports up to 8x anti-aliasing: Fast slicing, Hollowing, Split Model, Text Paste
High Performance Z-axis
The Z-axis is supported by dual linear rails,stepper motor and clearance nut combination which dramatically improves stability while in motion and reduces the risk of layer shifting.
New Matrix UV Light Source
High quality quartz lamp bead and new matrix design for uniform UV light energy. 4K monochrome LCD delivers high-quality prints
Anycubic APP Remote Control
Remote control of print operations,monitor printing progress,adjust the print settings
UV Cooling System
Cooling device for stable printing performance and longer service life.
Technical Specifications
- System : ANYCUBIC Photon Mono X
- Operation : 3.5 inch Touch Screen
- Software : ANYCUBIC Photon workshop
- Connectivity : USB
- Technology: LCD-based SLA
- Light-source: high-quality filament(wavelength 405nm)
- XY Res.: 0.050mm 3840*2400(4K)
- Z Axis Res.: 0.01mm
- Layer Res.: 0.01-0.15mm
- Printing Speed: MAX 60mm/h
- Rated Power: 120W
- Printer Size : 270mm(L)*290mm(W)*475mm(H)
- Build Volume: 192mm(L)*120mm(W)*245mm(H)
- Material: 405nm UV Resin
- Net Weight: ~10.75kg
